Published Writings 8 - as referred to by *

DESIGN 1

articles with Descriptive and Analytical/Critical content



'CLICK' on images for Caption and to review in Sequence.

Show More
Show More
PETER BLAKE scheme
Proposed First Floor
Adapting the existing House by revising/expanding/upgrading the facilities.
Proposed Second Floor
Shown overlaid on the First Floor, proposing a 'bridge' connection in a double-height volume.
Site Failure - 2013
As the Lake rises and falls every year, a large unseen boulder was pulled away.
Overall Terrace Failure
View looking South illustrates the conundrum of "starting over".
SITE view 1
A failure resulted in a collapse at the North end of the Site
SITE view 2
The result was the necessity of demolishing an outdated existing Structure, as may be seen from debris.
INITIAL SITE
Plan view documents the resulting Footprint.
NEW SITE
Stabilized North end shown; joint acquisition of adjacent South parcel with a neighbor, permitted relocation.
